INTERFACE MODEL 9840 VER 6.0.2
2. Full = 4.0000 Lb Zero = 4.0000 Lb
(Input) Mv/V (Output)Volt (Output) MA
4 0v 12mA
3 -2.5v 10mA
2 -5.0v 8mA
1 -7.5v 6mA
0 -10.0v 4mA
-1 -10.0v 4mA
-2 -10.0v 4mA
-3 -10.0v 4mA
-4 -10.0v 4mA
3. Full = 2.0000 Lb Zero = 0.0000 Lb
(Input) Mv/V (Output) Volt (Output) MA
4 10.0v 20mA
3 10.0v 20mA
2 10.0v 20mA
1 5.00v 16mA
0 0v 12mA
-1 -5.0v 8mA
-2 -10.0v 4mA
-3 -10.0v 4mA
-4 -10.0v 4mA
4. Full = 2.0000 Lb Zero = 2.0000 Lb
(Input) Mv/V (Output) Volt (Output) MA
4 10.0v 20mA
3 5.0v 16mA
2 0v 12mA
1 -5.00v 8mA
0 -10.00v 4mA
-1 -10.0v 4mA
-2 -10.0v 4mA
-3 -10.0v 4mA
-4 -10.0v 4mA
>Sensor Select
This menu is used to manually select load or torque cell calibration data from a list stored
in the Model 9840. When you select this menu on a 2 channel unit, you are asked to
select Channel A or B. The cell serial number of the selected channel is displayed. Use
either the left/right or plus/minus buttons to page through the list. The escape button will
MODEL 9840 PG 17 PUB. 2856-16
