Interflex IF-4735 User Manual

14 Configuring the Device
Explanation for devices of the IF-1xxx series
Term
Description
host baud rate
▪ 1 = 1,200
▪ 2 = 9,600
▪ 3 = 19,200
Token ring baud rate
Baud rate, TCP/IP network:
▪ 0 = 4 MB
▪ 1 = 16 MB
Baud rate
terminal bus 'n'
▪ 2 = 9,600
▪ 3 = 19,200)
▪
See also
Performing device license upgrade ........................................................................................ 16
6.2.7 Listing slave terminals
With the cfg command, you can list the configuration data of slave terminals.
Terminal configuration IF-xxxx V7.xx
--------------------------------------------------------------------
No B A HA TNo type HWU SWU display keys read.1 read.2 In/Out I/O
-- - - -- --- ---- --- --- ------- ---- ------ ------ ------ ----
1 1 A 1 0 IFx 2.04 6.b OL/2x20 ..NF PSCR/P ...... ...... --
2 1 B 2 0
............
16 3 F 15 0 IFx 2.04 6.b ../.... ..NF PSCR/P ...... ...... -+
Column
List of
B
3 bus interfaces with the terminal distribution, e.g. the factory-configured default
distribution of 6, 4 and 6 slave terminals
TNo
Host administration number. The numbers are configured in the time recording/access
control program and are only displayed after the data has been loaded.
type
Device type, e.g. the slave terminal IFxx
HWU
Hardware status, e.g. 2.04 for MPU hardware HCS12
SWU
Software status, e.g. version 6.b
read.1
First reader type, e.g. PSCR/P for MIFARE readers
read.2
Second reader type, e.g. FIP for slave terminals with fingerprint
In/Out
Configured RS232 interface, e.g. >RKASS< for a cashbox
