Interflex IF-57 Series Installation Instructions

Interflex Datensysteme GmbH 3/8
1.5 Cable lengths and cable types
Cable Function Max. Length Recommended Cable Type
230 VAC power supply to the optional power
supply unit
- 3 x NYM 1.5 mm²
Low-voltage cable for supplying power to the
terminal
-
J-Y(ST)Y 4  2  0.6 mm² or
Flex JZ 3  0.75 mm²
Ethernet/patch cable with/without PoE hub/switch
to the device
100 m Ethernet twisted pair cable (Cat5)
Ethernet/patch cable from hub/switch to the device 100 m
Ethernet twisted pair cable
Flexible patch cable (Cat5)
RS485 network cable 1200 m
J-Y(ST)Y 4  2  0.6 mm²
 Cable lengths: The specifications indicate the maximum permitted cable lengths that guarantee reliable
function.
 Cable types: Install only data and control cables with cable shielding, e.g. cable type J-Y (ST) Y or lines
of category 5.7.
To ensure trouble-free operation, we recommend the use of shielded cables.
 Operation is also possible with unshielded cables. In case of transmission problems, you will have to
examine the reasons in each individual case. Shielded cables may have to be provided for the
corresponding device.
1.6 Abbreviations
The following abbreviations are used in this document:
Abbreviation Description
AC Alternating Current
BLE Bluetooth Low Energy
CIDR Classless Inter-Domain Routing
DC Direct Current
DIP switch Switch in IC design, connections in two rows (Dual In-line Package)
EMC Electromagnetic compatibility
ESD Electrostatic discharge
GND Ground
IEEE Institute of Electrical and Electronics Engineers
NC contact Normally closed contact
NO contact Normally open contact
PoE Power over Ethernet
RFID Radio-Frequency Identification
SH Shield
SSH Secure shell
