Interflex IF-57 Series Installation Instructions

Interflex Datensysteme GmbH 7/8
4 Technical Specifications
Electrical Data
Nominal voltage 18 to 24 VAC/DC
Power supply via Ethernet (PoE) PoE device IEE 802.3 of power class 0 (up to 13 W).
Power consumption Approx. 13 VA
Interfaces
Data interface Ethernet network connection with SSH
TTL service interface
Reader
Reader type
Depending on the order, RFID technology: MIFARE,
LEGIC or SVP (SimonsVoss Active Technology)
Operating unit
Display
4.3 inch color display; resolution of 480  272 pixels
Touch Capacitive
General Data
Ambient temperature: +4°C to +40°C
Humidity Max. 95 %, non-condensing
Degree of protection IP30 (with concealed wiring)
Dimensions (W x H x D)
163  87  45.8 mm
Housing material Thermally tempered clear glass on a polycarbonate body
Weight 0.4 kg
Installation type Screw fastening (surface-mounted)
Cable feed Flush-mounted (or surface-mounted using spacers)
Color Black / white
Storage In a dry place
5 EU Declaration of Conformity
Interflex hereby declares that the products comply with the directives 2014/30/EU,
2014/35/EU and 2011/65/EU.
You can download the complete EU Declaration of Conformity on our website in the
Media / Download section: www.interflex.de/en/index.html
6 Disposal
Once its service life comes to an end, the device must be disposed of properly as
electronic waste. You can dispose of the device yourself or return it to the supplier.
