ECM20/ECL60 Installation and Operation Manual
Parameters-Default Setting
Parameters - Default Setting
PAR. ID961 ID971 ID974 U.M.
RANGE DEFAULT RANGE DEFAULT RANGE DEFAULT
SEt -50,0 ... 99,0 0,0 -50,0 ... 99,0 0,0 -50,0 ... 99,0 0,0 °C/°F
diF +0,1 ... +30,0 2,0 +0,1 ... +30,0 2,0 +0,1 ... +30,0 2,0 °C/°F
HSE LSE ... +302 99,0 LSE ... +302 99,0 LSE ... +302 99,0 °C/°F
LSE -58,0 ... HSE -50,0 -58,0 ... HSE -50,0 -58,0 ... HSE -50,0 °C/°F
OSP -30,0 ... +30,0 0,0 -30,0 ... +30,0 0,0 -30,0 ... +30,0 0,0 °C/°F
dOd n/y n n/y n n/y n flag
Ont 0 ... 250 0 0 ... 250 0 0 ... 250 0 min
dOn 0 ... 250 0 0 ... 250 0 0 ... 250 0 sec
dOF 0 ... 250 0 0 ... 250 0 0 ... 250 0 min
dbi 0 ... 250 0 0 ... 250 0 0 ... 250 0 min
OdO 0 ... 250 0 0 ... 250 0 0 ... 250 0 min
dty ----- ----- 0/1/2 0 0/1/2 0 flag
dit 0 ... 250 6 0 ... 250 6 0 ... 250 6 hours
dCt 0/1/2 1 0/1/2 1 0/1/2 1 flag
dOH 0 ... 59 0 0 ... 59 0 0 ... 59 0 min
dEt 1 ... 250 30 1 ... 250 30 1 ... 250 30 min
dSt ----- ----- -50,0 ... +150 8,0 -50,0 ... +150 8,0 °C/°F
dPO n/y n n/y n n/y n flag
FSt ----- ----- ----- ----- -50,0 ... +150 50,0 °C/°F
FAd ----- ----- ----- ----- +1,0 ... +50,0 2,0 °C/°F
Fdt ----- ----- ----- ----- 0 ... 250 0 min
dt ----- ----- ----- ----- 0 ... 250 0 min
dFd ----- ----- ----- ----- n/y y flag
FCO ----- ----- ----- ----- n/y/dc n flag
Fod ----- ----- ----- ----- n/y n flag
Att 0/1 1 0/1 1 0/1 1 flag
AFd +1,0 ... +50,0 2,0 +1,0 ... +50,0 2,0 +1,0 ... +50,0 2,0 °C/°F
HAL LAL ... +150,0 +50,0 LAL ... +150,0 +50,0 LAL ... +150,0 +50,0 °C/°F
LAL -50,0 ... HAL -50,0 -50,0 ... HAL -50,0 -50,0 ... HAL -50,0 °C/°F
CPdEFFAnAL
ECM20 ECL60
ALdiSCnFFPr
PAR. ID961 ID971 ID974 U.M.
RANGE DEFAULT RANGE DEFAULT RANGE DEFAULT
PAO 0 ... 10 0 0 ... 10 0 0 ... 10 0 hours
dAO 0 ... 999 0 0 ... 999 0 0 ... 999 0 min
OAO 0 ... 10 0 0 ... 10 0 0 ... 10 0 hours
tdO 0 ... 250 0 0 ... 250 0 0 ... 250 0 min
tAO 0 ... 250 0 0 ... 250 0 0 ... 250 0 min
EAL n/y n n/y n n/y n flag
LOC n/y n n/y n n/y n flag
PA1 0 ... 250 0 0 ... 250 0 0 ... 250 0 num
ndt n/y y n/y y n/y y flag
CA1 -12,0 ... +12,0 0,0 -12,0 ... +12,0 0,0 -12,0 ... +12,0 0,0 °C/°F
CA2 ----- ----- -12,0 ... +12,0 0,0 -12,0 ... +12,0 0,0 °C/°F
ddL 0/1/2 1 0/1/2 1 0/1/2 1 num
dro 0/1 0 0/1 0 0/1 0 flag
H00 0/1 1 0/1 1 0/1 1 flag
H08 0/1/2 2 0/1/2 2 0/1/2 2 num
H11 -6 ... +6 0 -6 ... +6 0 -6 ... +6 0 num
H25 ----- ----- ----- ----- 0 ... 6 4 num
H42 ----- ----- n/y y n/y y flag
rEL / / / / / / /
tAb / / / / / / /
UL / / / / / / /
Fr / / / / / / /
ECM20
ECL60
