Chapter 5: Menu reference
Advisor Advanced ATSx500A(-IP) Installation and Programming Manual 151
2.2.2.n.1 Expander type
The expander type is an informational screen. The type is set by the expander.
2.2.2.n.2 Expander address
2>Exp address
BUS: 1 ADDR: 1
The expander address is an informational screen providing the DIP switch
address.
2.2.2.n.3 Expander range
Expander range is an informational screen. It shows zone range available for this
expander.
Note: In case of 32-zone devices there are two zone ranges.
3>Expander range
113-128 353-368
See “2.2.2.n.4.6 Expander mode” on page 154 for more details.
2.2.2.n.4 Exp settings
The Expander settings menu contains menus shown below, which are necessary
to configure the selected expander.
Note: The available settings depend on the expander type.
2.2.2.n.4.1 Expander name
1 Expander name
>Expander 1 <
Use the Expander name option to enter a name that identifies the expander to
the end-user.
When an expander is created, it is given the default name “Expander <n>”,
where <n> is the expander address. Enter this menu to edit the current name.
An expander name can consist of 16 characters.
