Chapter 5: Menu reference
150 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual
See Advisor Advanced User Guide for more details.
This functionality is only available for ATS113x keypads.
2.2.1.n.3.21 Schedule
The shortcut menu allows you to assign up to two schedules to the selected
element.
See “Schedule shortcut menu” on page 78 for more information.
2.2.1.n.4 Keypad menu
The keypad menu provides access to the programming menu built-in to the
keypad. For more information, see the appropriate keypad manual.
2.2.1.n.5 Delete keypad
To remove the keypad, press Enter, select OK and press Enter again. The
keypad is deleted.
Note: Before removing a keypad, you should remove any outputs or condition
filters connected to the keypad.
2.2.2 Expander devices
0>Add expander
1 Expander 1
On the Expander devices menu, press 0 to add an expander, or a number to
configure an existing one.
Note: The maximum number of devices allowed on the databus is given in
“General features” on page 36.
Expander options
2.2.2.0 Add expander
One the Add expander menu, enter the number for the new expander and press
Enter to confirm, or Clear to exit without adding a device.
After the device is added, the expander configuration options are shown.
2.2.2.n Select expander
Select the expander number to configure.
To Next Page
