Chapter 5: Menu reference
174 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual
4.1.n.6.1 Inhibit
If the Inhibit option is set to Yes, this zone can be inhibited by user.
4.1.n.6.2 Isolate
If the Isolate option is set to Yes, this zone can be isolated by users.
4.1.n.6.3 Excl. in PS1
When a zone is programmed for excluding while part set (the Exclude in part set
option is set to Yes), it is excluded when the assigned area is part set. The
normal unset conditions, if relevant, continue to be monitored (tamper, masking,
etc). If the Exclude in part set option is set to No, the zone is set in both part set
and full set modes.
There are two independent part sets available, PS1 and PS2.
4.1.n.6.4 Excl. in PS2
See “4.1.n.6.3 Excl. in PS1” above.
4.1.n.6.5 Double knock
If the Double knock option is set to Yes, the zone requires two parameters to be
present in order to generate an alarm. If the zone becomes active and would
normally trigger an alarm, either the zone needs to remain active for the
programmed Double Knock open time (see “8.1.4.2 Double knock open” on page
235) or the zone has to return to normal and trigger again within the Double
Knock interval (see “8.1.4.1 Double knock interval” on page 235).
Note: If the option is active, the option “4.1.n.6.30 Held open” on page 179 is not
available.
4.1.n.6.6 Swinger shunt
If the Swinger shunt option is set to Yes, the number of alarms from this zone is
limited to the number set in “8.6.4 Swinger shunt” (see page 249) for one
set/unset cycle.
