Chapter 5: Menu reference
Advisor Advanced ATSx500A(-IP) Installation and Programming Manual 227
Schedule settings
7.2.0 Add schedule
Access the menu to add a schedule. If the schedule is created successfully, the
following message appears:
The new schedule is given the default name “Schedule N” and placed on the end
of the schedule list. You can now start editing the schedule details for the new
schedule.
7.2.n Select schedule
Select a schedule to program.
7.2.n.1 Schedule name
Every schedule can be programmed with a name to identify it.
Use the Schedule name screen to enter or edit the schedule name. The schedule
name can contain up to 16 characters.
7.2.n.2 Active
If set to Yes, the schedule is currently active.
7.2.n.3 Date
Enter the following dates:
• 1 Start date: The date of the schedule start.
• 2 End date: The date of the schedule end. Note that this date cannot be
earlier than the Start date.
7.2.n.4 Time
0>Add time frame
1 Time frame 1
Define time frames when the schedule activates.
