Chapter 5: Menu reference
228 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual
7.2.n.4.0 Add time frame
Access the menu to add a time frame. If the time frame is created successfully,
the following message appears:
The new time frame is given the name “Time frame N” and placed on the end of
the action list. You can now start editing the action details for the new action.
Caution: Time frames should not overlap.
7.2.n.4.m Select time frame
Select a time frame to program.
7.2.n.4.m.1 Start time
Provide the time of the day in 24-hour HH:MM format when the selected time
frame starts.
Note: Value 24:00 means that the time frame is not configured.
7.2.n.4.m.2 End time
Provide the time of the day in 24-hour HH:MM format when the selected time
frame ends. The value 00:00 means that the end time is not set, and therefore
the counteraction is not performed. See Chapter 3 “System functions >
Counteractions” on page 78 for more information.
7.2.n.4.m.3 Week days
Select days of the week when the selected time frame is active.
If no week day is selected, the schedule will only be valid on the first and the last
day (non-recurring schedule). In this case only one time frame can be used. See
also Chapter 3 “System functions > “Schedules” on page 77.
7.2.n.4.m.4 Delete time frame
To remove a time frame, select a time frame using the cursor, or by entering the
time frame number, and go to the Delete time frame menu.
The display shows:
