LOC PG DESCRIPTION DEFAULT YOUR DATA
243 12 PROGRAMMING THE ZONES
Seg 1 Door Shunt Zone 0 = Disabled
Seg 2 Request to Exit (RTE) 0 = Disabled
244 13 READER TIMES
Seg 1 Scan Time (1/100 seconds) 100 = 1 second
Seg 2 Relay Active Time (seconds) 10 = 10 seconds
Seg 3 Door Fault Warning Time (seconds) 30 = 30 seconds
Seg 4 Door Fault Alarm Time (seconds) 0 = 0 seconds
245 13 RESET THE READER ADDRESS
Entering a “0” will reset and cause the reader to
cease functioning.
246 13 PROGRAMMING THE ACCESS OPTIONS
Seg 1
DOOR OPTIONS
1 = "On" if locking mechanism is a Maglock or Drop Bolt.
2 = "On" if access is allowed regardless of Armed status of the system.
3 = "On" if the door is not to be latched unlocked during an open schedule.
4 = "On" if onboard open collector output only triggers during an open schedule.
5 = “On” if onboard open collector output only triggers during a close schedule.
6 = “On” if Forced Entry Alarm is logged.
7 = “On” if access allowed without an RTE.
8 = "On" if relay operates normally during off-schedule
Seg 2 SCHEDULES FOR ONBOARD OPEN COLLECTOR OUTPUT
1 = "On" if driver follows Schedule 1.
2 = "On" if driver follows Schedule 2.
3 = "On" if driver follows Schedule 3.
4 = "On" if driver follows Schedule 4.
5 = "On" if driver follows Schedule 5.
6 = "On" if driver follows Schedule 6.
7 = "On" if driver follows Schedule 7.
8 = "On" if driver follows Schedule 8.
Seg 3 MORE DOOR OPTIONS
1 = “On" if egress input is to be disabled
2 = Reserved
3 = Reserved
4 = Reserved
5 = Reserved
6 = Reserved
7 = Reserved
8 = Reserved
247 14
OPENING TIME FOR SCHEDULE 1
Seg 1 Hour of Opening Time (24-hr format) 8 = 8 AM
Seg 2 Minutes after Hour of Opening 0
248 14
CLOSING TIME FOR SCHEDULE 1
Seg 1 Hour of Closing Time (24-hr format) 20 = 8 PM
Seg 2 Minutes after Hour of Closing 0
NX-1701E Installation manual Page 18 31/01/05
