Interlogix TVB-5501 - Pin Definitions

24 Installation Guide
Dimensions
111 × 82.4 mm
(4.4 × 3.2 in.)
Weight
500 g (1.1 lbs.)
Environmental rating
IP67, IK10
Pin definitions
There are eight wires on a standard UTP/STP cable and each
wire is color-coded. The following shows the pin allocation and
color of straight and crossover cable connection:
Figure 4: Straight-through cable
1 White/Orange
White/Orange 1
2 Orange Orange 2
3 White-Green White-Green 3
4 Blue Blue 4
5 White/Blue White/Blue 5
6 Green Green 6
7 White/Brown White/Brown 7
8 Brown Brown 8
