EasyCoder PD41/PD42 Cutter Kit Installation Instructions 5
Cable clips
Cutter cable
Cutter
connector
5 Plug the cutter cable into the connector in the center section as shown.
Secure the cable to the bottom plate using the two cable clips included in
the kit.
6 Use the two plastic screws to attach the cutter spring to the cover (1). Hook
the cutter cover onto the cutter mechanism and lock the cover with the
screw at the bottom (2).
1
2
