Appendix A — Printer Specifications
PF8d and PF8t Desktop Printer User’s Guide 71
Tags and Strip With Slots
Tag and Strip With Slots: The label gap sensor is offset 2.5 mm (0.10 in) to the
left of the center of the media path.
Media Specifications
Measurement Value
Maximum tag or strip width (a) 116.0 mm (4.57 in)
Minimum tag or strip width (a) 25.0 mm (1.0 in)
Minimum tag length (b) 12.7 mm (0.5 in)
Minimum detection slot width (c) 14.0 mm (0.55 in)
Maximum detection slot height (d) 10.0 mm (0.39 in)
Minimum detection slot height (d) 3.0 mm (0.12 in)
Liner opacity 75%
a
b
c
d
Tickets, Tags, &
Continuous Strip
