Intermec PF8T User Manual

Appendix A — Printer Specifications
72 PF8d and PF8t Desktop Printer User’s Guide
Tags and Strip With Black Marks
Tag and Strip With Black Marks: The black mark sensor is centered on the
media path. The maximum reflectance is 5% at 940 nanometers. Carbon black.
Plain Continuous Stock
The PF8 printers can use continuous stock without any detection
slots or black marks. The printer must be set for continuous stock by
using the ESim Q command.
Media Specifications
Measurement Value
Maximum
tag or strip width (a) 116.0 mm (4.57 in)
Minimum
tag or strip width (a) 25.0 mm (1.0 in)
Minimum tag length (b) 12.7 mm (0.5 in)
Minimum detection slot/black mark width
(c) 14.0 mm (0.55 in)
Maximum black mark
height (d) 10.0 mm (0.39 in)
Minimum black mark
height (d) 3.0 mm (0.12 in)
Liner opacity 75%
a
b
c
d
Tickets, Tags, &
Continuous Strip

Intermec PF8T Specifications

General

Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Core diameter	25.4 mm
Ribbon length	274.32 m
Maximum media length	1727 mm
Maximum roll diameter	127 mm
Supported paper width	118 mm
Maximum media length (imperial)	68 \
Supported paper width (imperial)	4.65 \
RS-232 ports	1
Standard interfaces	USB 2.0
Connectivity technology	Wired
Form factor	Desktop
Dimensions (WxDxH)	168 x 218 x 116 mm
Flash memory	4 MB
Certification	CE, FCC Class A, cULus, UL, GS, TUVGS, CCC, C-TICK, BSMI
Internal memory	8 MB
Built-in barcodes	MaxiCode, PDF417
Page description languages	EPL
Compatible operating systems	Windows 98/Me/2000/XP Pro/Server 2003/Vista
Storage temperature (T-T)	40 - 104 °F
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Power requirements	100–240 V AC/50–60 Hz, 1.9 A
AC adapter output current	3 A
AC adapter output voltage	24 V

Weight and Dimensions

Weight	2000 g
