Important Safeguards
The illustrated label “WARNING MOVING PARTS” shown in Figure
4 is located on the “EXIT” end of the Left Hand side cover. The label
warns the operators and service personnel of the pinch point at the exit
ends of the machine.
Figure 4
The illustrated label “WARNING - MOVING
MACHINES PARTS” shown in Figure 5 is located on
the “Bottom Chain Guard” at the end of the Top Belt
Drive assembly. The label warns the operators and service
personnel of the pinch point at the exit ends of the
machine and under the guard.
Figure 5
