TROUBLE SHOOTING
The USA 2024-SB is fabricated with high quality components that provide trouble-free operation
for a long period of time. However, should a problem occur, we recommend that you consult the
following table. If the problem you encounter is not discussed in this table, call Interpack
Technical Support (see page 2 of this document).
Trouble Possible Causes Solutions
Green Start Button
Depressed But Belts Do
Not Turn
E-Stop not Re-Set
Machine Not Plugged In
Rotate E-Stop 1/4 Turn
Clockwise.
Plug Machine Into 115 V, 60 Hz,
15 Amp Electrical Service.
Motors Turn But Belts
Do Not Turn
Belt Tension Too Low Re-Tension Drive Belts, See
Section 11 page 51
Drive Belts Do Not
Process Cases.
Belt tension Too Low
Case Width Adjustment Incorrect.
Case Height Adjustment Incorrect.
Collapsed Leading End Panel On
Case.
Case Size Is Out Of Specification.
Top Squeezers Set Incorrectly.
Re-Tension Drive Belts, See
Section 11 page51
Re-Adjust Case Width, See
Section 8 page 39
Re-Adjust Case Height, See
Section 8 page 38
-Install Lighter Gauge Tape Head
Main Spring
-Reduce Unwind Tension On
Tape Roll
a. Mandrel Tension
b. Clutch Roller Tension
Compare Case Sizes With
Machine Specifications, Section
6 page 20
Re-Adjust Top Squeezers, See
Section 8 page 39
Case Processes But
Top Of Case Is
Crushed
Case Height Adjustment Is Incorrect Re-Adjust Case Height, See
Section 8 page 38
Case Processes But
Side Of Case Is
Crushed
Case Width Adjustment Incorrect Re-Adjust Case Width, See
Section 8 page 39
