UM094TW / UM594TW UDM094-04
48
P REVENTIVE M AINTENANCE
Lubricating the Machine
Figure-37
a. Column Shaft.
i. Lubricate Both Shafts With Industrial Grade Silicone.
b. Acme Drive Base Shafts.
i. Lubricate Both Shafts With Light Machine Grease.
c. Centering Chain.
i. Lubricate Chain With Chain Lubricant.
Column Shaft
Centering Chain
Acme Drive Base Shaft
