Interroll Drum motor series i, S, S/A, D
Version 4.1 (06/2015) en-US
Translation of original instruction manual
5
Encoder type BMB-6202 & 6205 SKF for the i-series 67
Technical data 67
Connections 68
Best connection option 69
Encoder type RM44-RLS for the i and D-series 70
Technical data 70
Connections 71
Signal connection 71
Resolver type RE-15-1-LTN 72
Connections 72
Technical data 72
Impedance 73
Transport and storage 74
Transport 74
Storage 75
Assembly and installation 76
Warning notices concerning the installation 76
Installing the drum motor 76
Positioning the drum motor 76
Installing the motor with mounting brackets 77
Installation considering hygienic aspects 79
Belt assembly 79
Belt width / tube length 79
Belt adjustment 79
Tensioning the belt 80
Belt tension 81
Belt elongation 81
Measuring the belt elongation 82
Calculating the belt elongation 82
Drum coating 83
Sprockets 83
Warning notices concerning the electrical installation 84
Electrical connection of the drum motor 84
Connecting the drum motor – with a cable 84
Connecting the drum motor – with a terminal box 84
Single-phase motor 84
External motor protection 85
Integrated thermal protection 85
Frequency inverter 85
Backstop 85
Electromagnetic brake 86
Initial startup and operation 88
Initial startup 88
Checks before the initial startup 88
Operation 89
Checks before every startup 89
Procedure in case of accident or fault 89
