341
GS
SAVE THESE INSTRUCTIONS
(341GS) MODEL SF90220RC-1 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/29/2021
English
Page 6
When ordering parts, be sure to quote the model number and part numbers.
REF.
NO.
DESCRIPTION
SPARE
PART NO.
QTY.
Individually
Pool set
1-1/2” (38mm)
Pool set
1-1/4” (32mm)
1 PRESSURE GAUGE 11720 1 1 1
2 TANK COVER & 6-WAY VALVE SET 11721B 1 1 1
3 DRAIN OUTLET COVER 11131 1 1 1
4 CLAMP ASSEMBLY 11722 1 1 1
5 TANK O-RING 11728 1 1 1
6 SAND FILTER PUMP MOTOR INLET O-RING 10712 1 1 1
7 CENTER PIPE 11729 1 1 1
8 FILTER GRID 11730 1 1 1
9 DRAIN VALVE CAP 11456 1 1 1
10 DRAIN VALVE O-RING 11385 1 1 1
11 L-SHAPE O-RING 11228 4 4 4
12 HOSE WITH NUTS 11010 2 2 2
13 SAND FILTER INTERCONNECETING HOSE 11763 1 1 1
14 POOL INLET AIR ADAPTOR 12368 - - 1
15 INLET STRAINER CONNECTOR 12365 - - 1
16 CLAMP PIN 11726 1 1 1
17 CLAMP SCREW 11727 1 1 1
18 L-SHAPE O-RING 11412 1 1 1
19 TRANSPARENT LEAF TRAP 11733 1 1 1
20 PUMP MOTOR 12704GS 1 1 1
21
PLUNGER VALVE (HOSE O-RING & STEP WASHER INCLUDED)
10747 - 2 -
22 HOSE O-RING 10262 - 2 -
23 STEP WASHER 10745 - 2 -
24 STRAINER NUT 10256 2 2 -
25 FLAT STRAINER RUBBER WASHER 10255 2 2 -
26 THREADED STRAINER CONNECTOR 10744 - 1 -
27 ADJUSTABLE POOL INLET JET NOZZLE 12369 1 1 -
28 ADAPTOR B 10722 - - 2
29 STRAINER CONNECTOR 11070 - - 1
30 POOL INLET JET NOZZLE 12364 - - 1
31 STRAINER GRID 12197 - - 1
32 10" SAND FILTER PUMP TANK 12711 1 1 1
33 10" SAND FILTER PUMP TANK BASE 12715 1 1 1
34 AIR JET VALVE CAP 12373 1 1 1
35 AIR RELEASE VALVE 10725 1 1 1
36 AIR RELEASE VALVE O-RING 10264 1 1 1
37 STRAINER GRID 12198 - 1 -
38 AIR JET VALVE 12363 1 1 1
39 INLET THREADED AIR CONNECTOR 12371 1 1 -
PARTS REFERENCE
(
continued
)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
