SAVE THESE INSTRUCTIONS
(195GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/20/2016
English
Page 5
REF. NO. DESCRIPTION QTY.
SPARE PART NO.
SF80220RC-1 SF70220RC-1 SF60220RC-1
1 PRESSURE GAUGE 1 11411 11224 11224
2 6-WAY VALVE 1 11378 11496 11496
3 DRAIN OUTLET COVER 1 11131 11131 11131
4 CLAMP 1 11380 11380 11380
5 TANK O-RING 1 11379 11379 11379
6 SAND SHIELD 1 11382 11382 11382
7 CENTER PIPE HUB 1 11815 11813 11814
8 LATERAL
10 11484
--
12 - 11384 11384
9 DRAIN VALVE CAP 1 11456 11456 11456
10 DRAIN VALVE O-RING 1 11385 11385 11385
11 L-SHAPE O-RING 4 11228 11228 11228
12 HOSE WITH NUTS 2 11769 11769 11769
13 SAND FILTER INTERCONNECTING HOSE 1 11820 11388 11535
14 LEAF TRAP NUT 1 11822 11479 11479
15 LEAF TRAP O-RING 1 11824 11232 11232
16 BASKET 1 11821 11260 11260
17 FILTER HOUSING NUT 1 11261 11261 11261
18 L-SHAPE O-RING 1 11412 11412 11412
19
AIR RELEASE VALVE/SEDIMENT RELEASE VALVE
2 10460 10460 10460
20 VALVE O-RING 2 10264 10264 10264
21*
PLUNGER VALVE (HOSE O-RING & STEP WASHER INCLUDED) 2 10747 10747 10747
22*
HOSE O-RING
2 10262 10262 10262
23*
STEP WASHER
2 10745 10745 10745
24*
STRAINER NUT
2 10256 10256 10256
25* FLAT STRAINER RUBBER WASHER 2 10255 10255 10255
26* THREADED STRAINER CONNECTOR 1 11235 11235 11235
27 ADJUSTABLE POOL INLET JET NOZZLE 1 12369 12369 12369
28*
ADAPTOR B
2 10722 10722 10722
29
*
STRAINER CONNECTOR 1
11070 11070 11070
30
*
POOL INLET JET NOZZLE 1 12364 12364 12364
31
*
STRAINER GRID
1
12197 12197 12197
32
SCREW
2 11381 11381 11381
33 PUMP MOTOR & CONTROL 1 12492GS 12488GS 12490GS
34 PRE-FILTER ASSEMBLY 1 11826 11371 11371
35 LEAF TRAP COVER 1 11823 11480 11480
36 SAND FILTER PUMP MOTOR INLET O-RING 2 11457 11457 11457
37 SAND FILTER PUMP TANK 1 11804 11802 11803
38 SAND FILTER PUMP TANK BASE 1 11816 11800 11801
39 PRE-FILTER HOUSING 1 12100 12099 12099
40* STRAINER GRID 1 12198 12198 12198
41* AIR JET VALVE 1 12363 12363 12363
42* INLET THREADED AIR CONNECTOR 1 12371 12372 12372
43* POOL INLET AIR ADAPTOR 1 12368 12368 12368
44* INLET STRAINER CONNECTOR 1 12365 12365 12365
45* AIR JET VALVE CAP (NOT SHOWN) 1 12373 12373 12373
" * ":
Optional.
When ordering parts, be sure to quote the model number and part numbers.
