SAVE THESE INSTRUCTIONS
(261IO) Sand Filter Pump & Saltwater System with Electrocatalysis Oxidation (14” & 16”) ENGLISH 7.5” X 10.3” PANTONE 295U 05/25/2018
Page 5
" * ":
These parts are not included if this pump was not purchased as part of a pool set. Contact our Authorized
Service Centers to order these parts if needed.
When ordering parts, be sure to quote the model number and part numbers.
REF. NO. DESCRIPTION QTY.
SPARE PART NO.
ECO20220-1/ECO20230-1 ECO15220-1/ECO15230-1
1 PRESSURE GAUGE 1 11224 11411
2
6-WAY VALVE SET 1
11496 11378
3
DRAIN OUTLET COVER 1
11131 11131
4
TANK O-RING 1
11379 11379
5 SCREW 2 11381 11381
6
CLAMP 1
11380 11380
7 SAND SHIELD 1 11382 11382
8
CENTER PIPE HUB 1
11814 11813
9
DRAIN VALVE CAP 1
11456 11456
10 DRAIN VALVE O-RING 1 11385 11385
11
LATERAL 10
11384 11384
12 HOSE WITH NUTS 2 11010 11010
13
SAND FILTER INTERCONNECTING HOSE 1
11536 11390
14
LEAF TRAP NUT 1
11479 11479
15
LEAF TRAP O-RING 1
11232 11232
16
BASKET 1
11260 11260
17 FILTER HOUSING NUT 1 11261 11261
18
L-SHAPE O-RING 4
11228 11228
19 SEDIMENT RELEASE VALVE 1 10460 10460
20
VALVE O-RING 1
10264 10264
21
FLOW SENSOR 1
11460 11460
22 ELECTROLYTIC CELL HOUSING
1
11372 11372
23 PRIMARY ELECTROLYTIC CELL
1
11374 11389
24 SECONDARY ELECTROLYTIC CELL 1 11905 11900
25
PRE-FILTER ASSEMBLY 1
11371 11371
26 PUMP MOTOR & CONTROL 1 12530/12530BS 12528/12528BS
27
L-SHAPE O-RING 1
11439 11439
28*
PLUNGER VALVE (HOSE O-RING & STEP WASHER INCLUDED)
2
10747 10747
29* HOSE O-RING 2 10262 10262
30*
STEP WASHER 2
10745 10745
31* STRAINER NUT 2 10256 10256
32* FLAT STRAINER RUBBER WASHER
2
10255 10255
33*
THREADED STRAINER CONNECTOR
1 11235 11235
34* ADJUSTABLE POOL INLET JET NOZZLE
1
12369 12369
35* ADAPTOR B
2
10722 10722
36* STRAINER CONNECTOR 1 11070 11070
37* POOL INLET JET NOZZLE
1
12364 12364
38* STRAINER GRID 1 12197 12197
39 TEST STRIPS
1
19635 19635
40
LEAF TRAP COVER 1
11480 11480
41 ELECTROLYTIC CELL NUT 1 11432 11432
42 TITANIUM ELECTRODE O-RING
1
11585 11585
43 CELL HOUSING 1 11915 11915
44
SAND FILTER PUMP MOTOR INLET O-RING 2
11457 11457
45 ELECTROLYTIC CELL NUT
1
11582 11582
46
SAND FILTER PUMP AND COMBO TANK 1
11803 11802
47
SAND FILTER PUMP TANK BASE 1
11801 11800
48 O-RING ON TITANIUM PLATES 1 11515 11515
49* STRAINER GRID 1 12198 12198
50* AIR JET VALVE 1 12363 12363
51* INLET THREADED AIR CONNECTOR 1 12372 12371
52* INLET STRAINER CONNECTOR 1 12365 12365
53* POOL INLET AIR ADAPTOR 1 12368 12368
54* AIR JET VALVE CAP (NOT SHOWN) 1 12373 12373
