Intex 24 User Manual

87PO
SAVE THESE INSTRUCTIONS
Page 7
(87PO) ROUND METAL FRAME POOL ENGLISH 7.5” X 10.3” PANTONE 295U 06/27/2008
English
PARTS REFERENCE
REF
NO.
DESCRIPTION
10’ X 30”
(305cm X 76cm)
12’ X 30”
(366cm X 76cm)
12’ X 36”
(366cm X 91cm)
SPARE PART NO.
1 2 3 4 5 6 7 8 9
10 11 12 13 14
PIN (WITH 2 EXTRA) SEAL (WITH 2 EXTRA) T - JOINT SPRING PIN LEG CAP HORIZONTAL BEAM POOL LINER (DRAIN VALVE CAP INCLUDED) <BLUE> VERTICAL LEG (SPRING PIN INCLUDED) RESTRAINING ROPE GROUND CLOTH (OPTIONAL) STRAINER HOLE PLUG (WITH 1 EXTRA) DRAIN CONNECTOR DRAIN VALVE CAP POOL COVER (OPTIONAL)
10426 10648 10463 10313 10576 10618 10615 10619 10127 10184 10649
10426 10648 10424 10313 10576 10618 10616 10619 10127 10184 10649
10426 10648 10424 10313 10576 10618 10879 10880 10127 10184 10649
13’ x 42”
(396cm x 107cm)
14 X 42”
(427cm X 107cm)
15’ X 36”
(457cm X 91cm)
10312 10648 11126 10313 10309 10414 11141 10589 10587 10127 10184 10649 11142
10312 10648 10310 10313 10309 10414 10987 10589 10587 10127 10184 10649 11054
10312 10648 10310 10313 10309 10414 10584 10590 10587 18932 10127 10184 10649 18901
REF
NO.
DESCRIPTION
15’ X 42”
(457cm X 107cm)
15’ X 48”
(457cm X 122cm)
16’ X 48”
(488cm X 122cm)
SPARE PART NO.
1 2 3 4 5 6 7 8 9
10 11 12 13 14
PIN (WITH 2 EXTRA) SEAL (WITH 2 EXTRA) T - JOINT SPRING PIN LEG CAP HORIZONTAL BEAM POOL LINER (DRAIN VALVE CAP INCLUDED) <BLUE> OR POOL LINER (DRAIN VALVE CAP INCLUDED) <GREY> VERTICAL LEG (SPRING PIN INCLUDED) RESTRAINING ROPE GROUND CLOTH (OPTIONAL) STRAINER HOLE PLUG (WITH 1 EXTRA) DRAIN CONNECTOR DRAIN VALVE CAP POOL COVER (OPTIONAL)
10312 10648 10310 10313 10309 10414 10585 10589 10587 18932 10127 10184 11044 18901
10312
10648 10861 10313 10309 10414 10586 10864 10587 18932 10127 10184 11044 18901
10312
10648 10861 10313 10309 10414 10764 10864 10317 18927 10127 10184 11044 10754
18’ X 48”
(549cm X 122cm)
18’ X 52”
(549cm X 132cm)
24’ X 52”
(732cm X 132cm)
10312 10648 10861 10313 10309 10414 10314 10864 10317 18933 10184 11044 18937
10312 10648 10862 10313 10309 10414 10766 10865 10317 18933 10184 11044 18937
10312 10648 10863 10313 10309 10414 10767 11043 10865 10420 18935 10184 11044 18929
