Intex 28241EH User Manual

(87PO) ROUND METAL FRAME POOL ENGLISH 7.5” X 10.3” PANTONE 295U 06/02/2020
SAVE THESE INSTRUCTIONS
Page 7
REF
NO.
DESCRIPTION
POOL SIZE & QUANTITIES
8’
(244cm)
10’
(305cm)
12’
(366cm)
13’
(396cm)
14’
(427cm)
15’
(457cm)
16’
(488cm)
18’
(549cm)
24’
(732cm)
1 T - JOINT 8 10 12 13 14 15 16 18 24 2
VERTICALLEG
8 10 12 13 14 15 16 18 24
3 LEGCAP 8 10 12 13 14 15 16 18 24 4 HORIZONTALBEAM 8 10 12 13 14 15 16 18 24 5
POOLLINER(DRAINVALVECAPINCLUDED)
1 1 1 1 1 1 1 1 1
6 DRAINVALVECAP 1 1 1 1 1 1 1 2 2 7 GROUNDCLOTH
- - - - -
1 1 1 1
8 STRAINERHOLEPLUG 3 3 3 3 3 3 3 2 2 9 DRAINCONNECTOR 1 1 1 1 1 1 1 1 1
10 POOL COVER
- - -
1 1 1 1 1 1
11 HOSE 2 2 2 2 2 2 2 2 2 12 HOSET-JOINT 1 1 1 1 1 1 1
- -
13 HOSECLAMP 8 8 8 8 8 8 8 4 4 14 STRAINERCONNECTOR 2 2 2 2 2 2 2 2 2 15 STRAINERGRID 2 2 2 2 2 2 2 2 2 16 POOLINLETJETNOZZLE 1 1 1 1 1 1 1
- -
17 HOSEO-RING
- - - - - - -
1 1
18
PLUNGERVALVE(HOSEO-RING&STEP WASHERINCLUDED)
- - - - - - -
1 1
19 STEPWASHER
- - - - - - -
1 1
20 STRAINERNUT
- - - - - - -
1 1
21 FLATSTRAINERRUBBERWASHER
- - - - - - -
1 1
22
INLETTHREADEDAIRCONNECTOR+
- - - - - - -
1 1
23
ADJUSTABLEPOOLINLETJETNOZZLE
- - - - - - -
1 1
24 SPLITHOSEPLUNGERVALVE
- - - - - - -
1 1
25
INLETSTRAINERCONNECTOR
1 1 1 1 1 1 1
- -
26
AIR JET VALVE
1 1 1 1 1 1 1 1 1
27
POOLINLETAIRADAPTOR+
1 1 1 1 1 1 1
- -
28
AIR JET VALVE CAP (NOTSHOWN)
1 1 1 1 1 1 1 1 1
+Ifapplicable,dependingonthesizeofthefilterpumpfittedwithyourpool,youmustquotethemodelnumbershownonthefilterpumphousingtoorder thecorrectsizeof“
Pool Inlet Air Adaptor
”or
“Inlet Threaded Air Connector”
replacement part.

Intex 28241EH Specifications

General

Brand	Intex
Model	28241EH
Category	Swimming Pool
Language	English
