Intex 28241EH User Manual

(87PO) ROUND METAL FRAME POOL ENGLISH 7.5” X 10.3” PANTONE 295U 06/02/2020
SAVE THESE INSTRUCTIONS
Page 8
REF
NO.
DESCRIPTION
8’ X 20”
(244cm X 51cm)
10’ X 30”
(305cm X 76cm)
10’ X 30”
(305cm X 76cm)
Printing
12’ X 30”
(366cm X 76cm)
12’ X 33”
(366cm X 84cm)
12’ X 36”
(366cm X 91cm)
12’ X 39”
(366cm X 99cm)
13’ X 39”
(396cm X
99cm)
14 X 42”
(427cm X
107cm)
15’ X 33”
(457cm X 84cm)
15’ X 36”
(457cm X 91cm)
15’ X 42”
(457cm X
107cm)
15’ X 48”
(457cm X
122cm)
16’ X 42”
(488cm X
107cm
)
18’ X 48”
(549cm X
122cm)
24’ X 52”
(732cm X
132cm)
SPARE PART NO.
1 T - JOINT 13010 12798 12798 12798 12798 12798 12798 12799 12799 12799 12799 12799 12799 12799 12800 12800
2
VERTICALLEG
13012 12810 12810 12810 12811 12812 12813 12815 12816 12817 12337 12816 12818 12816 12819 12820
3 LEGCAP
11574D
10309 10309 10309 10309 10309 10309 12138 12138 12138 12138 12138 12138 12138 12139 12139
4 HORIZONTALBEAM 13011 12807 12807 12807 12807 12807 12807 12808 12808 12808 12808 12808 12808 12808 12809 12809
5
POOLLINER(DRAINVALVECAPINCLUDED)
13001EH 10095E 13022EH 10096E 12883E 12884E 12885E 12887E 12888E 10097E 12890E 12891E 10098E 12892E 10099E 12894E
6 DRAINVALVECAP 10649 10649 10649 10649 10649 10649 10649 10649 10649 10649 10649 11044 11044 11044 11044 11044
7 GROUNDCLOTH
- - - - - - - - -
18932 18932 18932 18932 18927 18933 18935
8 STRAINERHOLEPLUG 10127 10127 10127 10127 10127 10127 10127 10127 10127 10127 10127 10127 10127 10127 10127 10127
9 DRAINCONNECTOR 10184 10184 10184 10184 10184 10184 10184 10184 10184 10184 10184 10184 10184 10184 10184 10184
10 POOL COVER
- - - - - - -
11142 11054 18901 18901 18901 18901 10754 18937 18929
11 HOSE 11873 11873 11873 11873 11873 11873 11873 11873 11873 11873 11873 11873 11873 11873 11873 11873
12 HOSET-JOINT 11871 11871 11871 11871 11871 11871 11871 11871 11871 11871 11871 11871 11871 11871
- -
13 HOSECLAMP 11489 11489 11489 11489 11489 11489 11489 11489 11489 11489 11489 11489 11489 11489 10122 10122
14 STRAINERCONNECTOR 11070 11070 11070 11070 11070 11070 11070 11070 11070 11070 11070 11070 11070 11070 11070 11070
15 STRAINERGRID 11072 11072 11072 11072 11072 11072 11072 11072 11072 11072 11072 11072 11072 11072 11072 11072
16 POOLINLETJETNOZZLE 12364 12364 12364 12364 12364 12364 12364 12364 12364 12364 12364 12364 12364 12364
- -
17 HOSEO-RING
- - - - - - - - - - - - - -
10262 10262
18
PLUNGERVALVE(HOSEO-RING &STEPWASHERINCLUDED)
- - - - - - - - - - - - - -
10747 10747
19 STEPWASHER
- - - - - - - - - - - - - -
10745 10745
20 STRAINERNUT
- - - - - - - - - - - - - -
10256 10256
21
FLATSTRAINERRUBBERWASHER
- - - - - - - - - - - - - -
10255 10255
22
INLETTHREADEDAIRCONNECTOR+
- - - - - - - - - - - - - -
12371 12372
12371 12372
23
ADJUSTABLEPOOLINLETJETNOZZLE
- - - - - - - - - - - - - -
12369 12369
24 SPLITHOSEPLUNGERVALVE
- - - - - - - - - - - - - -
11872 11872
25
1-1/4”INLETSTRAINERCONNECTOR
12365 12365 12365 12365 12365 12365 12365 12365 12365 12365 12365 12365 12365 12365
- -
26
AIR JET VALVE
12363 12363 12363 12363 12363 12363 12363 12363 12363 12363 12363 12363 12363 12363 12363 12363
27
POOLINLETAIRADAPTOR+
12366 12367 12368
12366 12367 12368
12366 12367 12368
12366 12367 12368
12366 12367 12368
12366 12367 12368
12366 12367 12368
12366 12367 12368
12366 12367 12368
12366 12367 12368
12366 12367 12368
12366 12367 12368
12366 12367 12368
12366 12367 12368
- -
28
AIR JET VALVE CAP (NOTSHOWN)
12373 12373 12373 12373 12373 12373 12373 12373 12373 12373 12373 12373 12373 12373
12373 12373
+Ifapplicable,dependingonthesizeofthefilterpumpfittedwithyourpool,youmustquotethemodelnumbershownonthefilterpumphousingtoorder thecorrectsizeof“
Pool Inlet Air Adaptor
”or
“Inlet Threaded Air Connector”
replacement part.
