Intex Auto Cleaner User Manual

100
IO
SAVE THESE INSTRUCTIONS
Page 7
(100IO) AUTO CLEANER ENGLISH 7.5” X 10.3” PANTONE 295U 08/05/2008
English
SSEETT--UUPP IINNSSTTRRUUCCTTIIOONNSS
3. From inside of the pool, unscrew the nozzle from the water return
connector (upper hose connection). See Fig. 3.
4. Screw the hose adaptor (7) to hose
A (8). See Fig. 4.
NOTE: Please use hose adaptor for
small AGP pool (12) instead of hose
adaptor (7) If your pool comes
with 1-1/4" outlet.
5. Screw the end of hose A (8) with
adaptor to the threaded strainer
connector, from inside of the pool.
See Fig. 5.
SET-UP INSTRUCTIONS (continued)
3
4
7
8
5
Threaded Strainer
Connector
8
Lower Hose
Connection
Upper Hose
Connection
Threaded Strainer
Connector
nozzle
Inside of
the Pool
Wall

Intex Auto Cleaner Specifications

General

Compatibility	Above Ground Pools
Pool Type	Above-ground
Cleaning Coverage	Floor
Suitable For	Above-ground pools
Warranty	1-year limited warranty
