Intex CS15220 User Manual

241A
SAVE THESE INSTRUCTIONS
(241IO) SALTWATER SYSTEM & SAND FILTER PUMP (14” & 16”) ENGLISH 7.5” X 10.3” PANTONE 295U 08/09/2013
English
Page 5
" * ": Optional.
When ordering parts, be sure to quote the model number and part numbers.
PARTS REFERENCE (continued)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
REF. NO. DESCRIPTION QTY.
SPARE PART NO.
CS20220/CS20230 CS15220/CS15230
1 PRESSURE GAUGE 1 11224 11411
2 6-WAY VALVE SET 1 11496 11378
3 DRAIN OUTLET COVER 1 11131 11131
4 TANK O-RING 1 11379 11379
5 SCREW 2 11381 11381
6 CLAMP 1 11380 11380
7 SAND SHIELD 1 11382 11382
8 CENTER PIPE HUB 1 11814 11813
9 DRAIN VALVE CAP 1 11456 11456
10 DRAIN VALVE O-RING 1 11385 11385
11 LATERAL 10 11384 11384
12 HOSE WITH NUTS 2 11010 11010
13 SAND FILTER INTERCONNECTING HOSE 1 11536 11390
14 LEAF TRAP NUT 1 11479 11479
15 LEAF TRAP O-RING 1 11232 11232
16 BASKET 1 11260 11260
17 FILTER HOUSING NUT 1 11261 11261
18 L-SHAPE O-RING 4 11228 11228
19 SEDIMENT RELEASE VALVE 1 10460 10460
20 VALVE O-RING 1 10264 10264
21 FLOW SENSOR 1 11460 11460
22 ELECTROLYTIC CELL 1 11372 11372
23 TITANIUM ELECTRODE 1 11374 11389
24 COPPER ELECTRODE 1 11234 11234
25 PRE-FILTER ASSEMBLY 1 11371 11371
26 PUMP MOTOR & CONTROL 1 11812 11810
27 L-SHAPE O-RING 1 11439 11439
28*
PLUNGER VALVE (HOSE O-RING & STEP WASHER INCLUDED) 2 10747 10747
29* HOSE O-RING 2 10262 10262
30* STEP WASHER 2 10745 10745
31* STRAINER NUT 2 10256 10256
32* FLAT STRAINER RUBBER WASHER 2 10255 10255
33*
THREADED STRAINER CONNECTOR 2 11235 11235
34* ADJUSTABLE POOL INLET NOZZLE 1 11074 11074
35* ADAPTOR B 2 10722 10722
36* STRAINER CONNECTOR 2 11070 11070
37* POOL INLET NOZZLE 1 11071 11071
38* STRAINER GRID 1 11072 11072
39 CHLORINE TEST STRIPS 1 19635 19635
40 COPPER TEST STRIPS 1 11254 11254
41 LEAF TRAP COVER 1 11480 11480
42 ELECTROLYTIC CELL NUT 1 11432 11432
43 COPPER ELECTRODE O-RING 1 11440 11440
44 COPPER ELECTRODE HOUSING 1 11441 11441
45 SAND FILTER PUMP MOTOR INLET O-RING 2 11457 11457
46 COPPER ELECTRODE NUT 1 11488 11488
47 SAND FILTER PUMP AND COMBO TANK 1 11803 11802
48 SAND FILTER PUMP TANK BASE 1 11801 11800
49 O-RING ON TITANIUM PLATES 1 11515 11515
