• No air pump maintenance is required.
• Recommended working pressure: 0.025bar (0.36psi).
• The appliance must be positioned so that the plug is accessible.
• For cleaning use only mild soapy solution. Do not use any chemicals.
• In case of repairs, use only common PVC repair glue and patches.
NOTE: Drawings for illustration purpose only. May not reflect actual product. Not to scale.
Due to a policy of continuous product improvement, Intex reserves the right to change
specifications and appearance, which may result in updates to the instruction manual,
without notice.
PARTS REFERENCE
Part Descriptions:
1. AC line cord
2. Switch
3. Inflation mark ( )
4. Off mark (
)
5. Deflation mark (
)
6. Air passage
7. Cord compartment
8. Cordcompartmentcover
9.
Inflation valve & valve cap
10. Airbed
In order to avoid a hazard due to inadvertent resetting of the
thermal cut-out this appliance must not be supplied through an
external switching device, such as a timer, or connected to a
circuit that is regularly switched on and off by the utility.
CAUTION
INSTRUCTIONS
General
10
3
4 5
2
6
9
1
8
7
