SAVE THESE INSTRUCTIONS
(120PO) ENGLISH 7.5” X 10.3” PANTONE 295U 10/10/2018
English
Page 13
POOL SETUP (continued)
YoumayhavepurchasedthispoolwiththeIntexKrystalClear™filterpump.Thepumphasits
own separate set of installation instructions. First assemble your pool unit and then set up the
filter pump.
Estimatedassemblytime120minutes.(Notetheassemblytimeisonlyapproximateand
individualassemblyexperiencemayvary.)
1. Liner preparation
• Openthecartoncontainingtheliner,joints,legs,etc.,verycarefullyasthiscartoncanbeusedtostore
the pool during the winter months or when not in use.
• Takeoutthegroundcloth
(11)
andspreaditoverthe
cleared area. Then take out the liner
(8) and spread it out
 overthegroundcloth,withthedrainvalvedirectedtowards
 thedrainingarea.Placethedrainvalveawayfromthe
house. Allow the sun to warm up the liner before inserting
the beams
(7)
intothesleeveopenings.
IMPORTANT: Always set up the pool unit with at least
2 persons. Do not drag the liner across the ground as
this can cause liner damage and pool leakage
(see drawing 4).
• Duringtheset-upofthepoolliner,pointthehoseconnectionsoropeningsinthedirectionoftheelectric
 powersource.Theouteredgeofthepoolshouldbewithinreachofthepump’selectricalconnection.
2. Frame assembly
• Theframepool’slegs
(5) and beams (7)
fallintotwogroups.Thelargerdiametersarethehorizontal
 beamsthatareslid(pushed)intothesleeveopeningsatthetopoftheliner.Thesmallerdiametersare
 theverticallegs.BoththeselegsandbeamsfitintotheT-joints
(3).
NOTE: Sprinkle some talcum powder over the horizontal beams before sliding them into the pool
liner sleeve. This will make removal of the beams from the liner easier during the disassembly of
the pool.
• Startingatanylocation,butalwaysworkinginthesamedirection,push
 thehorizontalbeamintothesleeve.Oncethebeamiscenteredtakeone
of the T- joints and using the connection pin
(1), attach the joint to one
end of the beam by inserting the pin through the seal
(2) and in the
pre-drilled holes. Repeat this procedure in a circular fashion until all the
 beamsandjointshavebeenconnected
(see drawing 5.1).
The last joint connection may be difficult to complete. You can do
it though, if you first simultaneously raise the last joint and beam
about 2 inches (5 cm). Now, insert the beam into the joint while
lowering the pieces into position. The beam will easily slide into
the joint (see drawing 5.2). Ensure that the last joint is fully
connected before proceeding to connecting the legs.
8
4
1
2
7
3
5.1
5.2
3
