English
Page 17
POOL ENCLOSURE SETUP (continued)
15'8"x49"
18’8”x53”
11.7
8
7
6
5
4
3
2
1
11.8
8
7
6
5
4
3
2
1
0
4a-2. For Pools with Dual Suction Outlets Configuration:
 • PlacetheL-shapeo-ring
(35)
on the lower position of the threaded strainer connectors. In a clockwise
motion screw the adaptor A
(40)
ontothethreadedstrainerconnectors(Seedrawing12.1,12.2&12.3).
  Note:Removethestrainervalvecap
(19) from the threaded strainer connectors when connecting filter
pump with it.
12.1
12.2
12.3
 • Side panel with one hole installation
 Slidethesideboardfirstdownthesupportpostsandinsertontotheverticaledgeofthebottomrail.
  Followwiththenumbersequencefrombottomtotop.Thegrooveoftheboardneedstobeinserted
  fullyontothetongueofthepreviousboard.Thenslidethesideboardcombinationwithonehole
(41)
  throughthesupportpostsandinsertontothetongueofsideboardmarkedwithnumber“4”
  (seedrawings12.4&12.5).
12.4
12.5
