(257PO) MODEL 601 FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 05/31/2021
English
SAVE THESE INSTRUCTIONS
Page 4
257
PO
NOTE:
Drawings for illustration purpose only. May not refl ect actual product. Not to scale.
1
2
3
12
4
5
13 10
119
14
15
8
7
6
ABC
16
PARTS REFERENCE
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
When ordering parts, be sure to quote the model number and part numbers.
No tools are required for the assembly.
REF. NO. DESCRIPTION QTY. SPARE PART NO.
1 AIR RELEASE VALVE 1 10460
2 VALVE O-RING 1 10264
3 FILTER HOUSING COVER 1 11917
4 COVER SEAL 1 11919
5 FILTER CARTRIDGE 1 29007
6 HOSE SEAL 2 10134
7 HOSE CLAMP 4 11489
8 HOSE 2 11916
9 STRAINER CONNECTOR 1 11070
10 POOL INLET JET NOZZLE 1 12364
11 STRAINER GRID 1 11072
12 THREADED FILTER HOUSING COLLAR 1 11918
13 INLET STRAINER CONNECTOR 1 12365
14 AIR JET VALVE 1 12363
15 POOL INLET AIR ADAPTOR 1 12366
16 AIR JET VALVE CAP 1 12373
