S AVE THESE INSTRUCTIONS
(264IO) SPA (JET + BUBBLE) ENGLISH 7.5” X 10.3” PANTONE 295U 11/21/2014
English
Page 7
When ordering parts, be sure to quote the model number and part numbers.
PARTS (continued)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
REF. NO. DESCRIPTION QTY.
PART NO.
1 CONTROL BASE 1
11948
2
SPA FILTER MOTOR 1 11888
3 CONTROL PANEL (INCLUDED #4) 1
11949
4 CONTROL PANEL BOLT 3 11996
5 PRESSURE GAUGE 1 11741
6 CONTROL PANEL BOLT WRENCH 1 11053
7 SPA INFLATION HOSE 1 11830
8 SPA CONTROL INLET/OUTLET O-RING 2 11788
9 SPA CONTROL JET AIR INLET O-RING 1 11699
10 SPA DRAIN PLUG 1
11995
11 SPA DRAIN VALVE ADAPTOR 1 11718
12 FILTER CARTRIDGE HOUSING 1 11798
13 FILTER CARTRIDGE 2 11692
14 FILTER CARTRIDGE HOUSING LID 1 11797
15 INLET PLUG 1 11739
16 SPA TUB 1
11946
17 SPA COVER 1 11951
18
SPA COVER INFLATABLE BLADDER (PRE-INSTALLED IN SPA COVER)
1
11884
19 GROUND CLOTH 1 11717
20 ELECTROLYTIC CELL NUT WRENCH 1 11854
21 TEST STRIPS 1 11855
22 WRENCH 1 11742
23 OUTLET PLUG 2 11782
24 CONTROL PANEL JET AIR HOSE CONNECTION O-RING 1 11711
25 MALE BUCKLE 8 11994
26 FEMALE BUCKLE
8 11993
27 SPA CONTROL AIR INLET O-RING 1 11687
28 ELECTROLYTIC CELL COVER SCREW 4 11712
29 ELECTROLYTIC CELL COVER 1 11890
30 ELECTROLYTIC CELL COVER O-RING 1 11897
31 ELECTROLYTIC CELL NUT 1 11852
32 ELECTROLYTIC CELL 1 11851
33 ELECTROLYTIC CELL O-RING 1 11853
34 DEFLATION OUTLET CAP 1 11992
35 DEFLATION HOSE ADAPTOR 1 11935
36 INFLATION HOSE ADAPTOR 1 11829
37 CONTROL BASE INFLATION CAP 1 11991
To Next Page
