Intex SF15220 User Manual

162
SAVE THESE INSTRUCTIONS
Page 8
(162) MODEL SF15220 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 09/28/2010
English
When ordering parts, be sure to quote the model number and part numbers.
PARTS REFERENCE (continued)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
PPAARRTTSS RREEFFEERREENNCCEE
REF. NO. DESCRIPTION QTY.
SPARE PART
NO.
1
PRESSURE GAUGE
1 11411
2
6-WAY VALVE
1 11378
3
DRAIN OUTLET COVER
1 11131
4
CLAMP
1 11380
5
TANK O-RING
1 11379
6
SAND SHIELD
1 11382
7
CENTER PIPE HUB
1 11383
8
LATERAL
10 11384
9
DRAIN VALVE CAP
1
11226
10
DRAIN VALVE O-RING
1 11385
11
L-SHAPE O-RING
4 11228
12
HOSE WITH NUTS
2 11010
13
SAND FILTER INTERCONNECTING HOSE
1 11388
14 LEAF TRAP COVER 1 11259
15 LEAF TRAP O-RING 1 11232
16 BASKET 1 11260
17 FILTER HOUSING NUT 1 11261
18
L-SHAPE O-RING
1 11412
19 SEDIMENT RELEASE VALVE 1 10460
20 VALVE O-RING 1 10264
21 PLUNGER VALVE (HOSE O-RING & STEP WASHER INCLUDED) 2 10747
22
HOSE O-RING
2 10262
23
STEP WASHER
2 10745
24
STRAINER NUT
2 10256
25
FLAT STRAINER RUBBER WASHER
2 10255
26
THREADED STRAINER CONNECTOR
2 11235
27
ADJUSTABLE POOL INLET NOZZLE
1 11074
28
ADAPTOR B
2 10722
29
STRAINER CONNECTOR
2 11070
30
POOL INLET NOZZLE
1 11071
31
STRAINER GRID
1 11072
32
SCREW
2 11381
33
PUMP MOTOR & CONTROL
1 11386
34
PRE-FILTER ASSEMBLY
1 11371
