14
TRAY ADJUSTMENT AND STORAGE
(FIGURE 4)
The tray can be adjusted by pulling down the relase pin
(rotating the pin will lock it open) located under the arm
tube. The adjustment is in 1" increments.
Ensure the tray is securely locked in place before using.
To store the tray place one of the tray rods in the arm
tube with the top surface of the tray facing away from the
chair.
FIGURE 4 - TRAY ADJUSTMENT AND STORAGE
ADJUSTMENT
STORAGE
A
D
J
U
S
T
M
E
N
T
S
PROCEDURE 4 ADJUSTMENTS
