SECTION 2—PARTS AND INSTALLATION
Side Entry Whirlpool Tub 14 Part No 1118387
SECTION 2—PARTS AND
INSTALLATION
Parts Information
Forpartsinformation,pleasecontactICCITechnicalServiceat(800)668‐2337.
About Installation
 WARNING
Access for servicing the tub MUST be provided. Install the tub in a location that will
permit access to the service panels, plumbing and electrical hook-ups.
CAUTION
DO NOT lift the tub by the plumbing.
DO NOT remove or relocate the pump. Modifications to the pump location may
cause the system to malfunction and will void the warranty.
Thetubsarefree‐standingside‐entrybathingandhydromassagetubswhicharesecured
tothefloor.
Preparing the Work Area
NOTE:Forthisprocedure,refertoFIGURE 2.1onpage15.
1. Determinelocationforthetubinstallation.
NOTE:FollowrecommendedfloorplanshowninFIGURE 2.1onpage15wheninstallingthetub.
2. Carefullyremovethetubfromcarton.
3. Removetubfromshippingpalletbyremovingscrewsfromlegmountingpads(Detail
“A”).
4. Removethe
fourscrewssecuringtheserviceaccesspanel(FIGURE 2.1).
