SECTION 3—OPERATING INSTRUCTIONS
Side Entry Whirlpool Tub 26 Part No 1118387
Operating Shower/Massage Wand
NOTE:Forthisprocedure,refertoFIGURE 3.4.
NOTE:STEPS1‐3aretobeperformedwhileholdingtheshower/massagewandoverthetub.
1. Turnshower/massagewandontodesiredflowbyrotatingshowerOn/Offvalve
(Detail“A”).
2. Adjustwatertemperatureusingthewatertemperaturevalvewhilewatchingtheflow
waterthermometer(Detail“B”).
3. Adjustshowerspraybyrotatingshowerwandhead(Detail“C”).
NOTE:Refertofollowingchartforshowerheadadjustmentsettings.
4. TurnshowerOn/Offvalvetooffpositionwhenfinished.
FIGURE 3.4 Operating Shower/Massage Wand
Filling Tub
NOTE:Forthisprocedure,refertoFIGURE 3.5onpage27.
1. Closethedrain(Detail“A”).
2. TurntubfillOn/Offvalvetoonpositionbyrotatingvalve(Detail“B”).
3. Adjustwatertemperatureusingthewatertemperaturevalvewhilewatchingflow
waterthermometer(Detail“C”).
CAUTION
Before starting hydromassage, water level MUST be completely above whirlpool
jets otherwise severe damage to the motor/pump will result.
4. TurntubfillOn/Offvalvetooffpositionwhenwaterreachesdesiredlevel(Detail“B”).
Stream
Shower Spray
Mixture of Spray and Pulse Massage
Pulse Massage
Water
Temperature
Valve
Flow Water
Thermometer
Shower On/Off Valve
Shower/Massage
Wand
Head
DETAIL “C”DETAIL “B”DETAIL “A”
