SECTION 3—OPERATING INSTRUCTIONS
Side Entry Whirlpool Tub 24 Part No 1118387
Opening/Closing the Tub Door
 WARNING
DO NOT open door when water is in the tub, serious injury could result.
NOTE:Forthisprocedure,refertoFIGURE 3.2onpage24.
Opening the Tub Door
1. Placeonehandontopofthedoorhandle.
2. Usetheotherhandtopullthesafetypinoutandreleasethedoorhandle.
3. Liftuponthedoorhandleandopenthedoor.
Closing the Tub Door
 WARNING
DO NOT fill or use tub if door does not lock - otherwise serious injury or damage
may result. If the door does not lock, contact a qualified maintenance technician.
1. Closethedoor.
2. Pushdownonthedoorhandletolockdoorintoposition.
3. Liftthedoorhandletoensurethesafetypinhasengagedthedoorproperly.
4. Ifthedoorhandlelifts,repeatSTEPS1‐3.
FIGURE 3.2 Opening/Closing the Tub Door
Door
Handle
Safety
Pin
Door
Model 3650
Door
Handle
Safety
Pin
Models 3600 and 3600XL
