SECTION 3—OPERATING INSTRUCTIONS
Part No 1118387 23 Side Entry Whirlpool Tub
Disinfecting the Tub Using the Closed Loop System
WARNING
• Disinfect the tub after EACH use to avoid resident infection and contamination of the tub.
• DO NOT disinfect the tub when it is occupied. Otherwise injury may occur.
• Read and understand all information on Invacare brand disinfectant before use.
• ALWAYS wear rubber gloves, an apron and a face shield when using disinfectant. In case of eye or skin
contact, follow procedures on disinfectant container.
• The disinfectant dispensing system has been factory tested and calibrated for use with Invacare disinfectant.
The use of any disinfectant with a dilution ratio (½ oz. per gallon) or viscosity level different than that of
Invacare disinfectant will result in an improper mixture of disinfectant and water. This may cause your
system to be improperly disinfected - or in some instances, not disinfected at all. If using any disinfectant with
a dilution ratio or viscosity level different than that of Invacare disinfectant or if switching from one type of
disinfectant to another type, the disinfectant flowmeter MUST be calibrated before performing this
procedure. Refer to Calibrating the Disinfectant Flow Meter
on page 32.
• DO NOT use the disinfectant wand for showering. The disinfectant wand is to be used for disinfecting ONLY.
CAUTION
• NEVER use abrasive cleaners like scouring powder or liquid cleaners containing pumice stone. The use of
these types of cleaners will make the gel-coat finish of your tub scratched and dull. NEVER use cleaners
containing iodine, bromine, Betadine or methylene blue. The use of these types of cleaners will cause the tub
to stain. Never use cleaners containing bleach. Use of these types of cleaners will dry out the rubber seals and
gaskets and the tub will not function properly.
NOTE:Forthisprocedur e,refertoFIGURE 3.1.
NOTE:Ensurethatthewhirlpooljetsandwhirlpoolinletfittingareclosedbe forestarti ngthisprocedure.
1. Cleantheentiretubsurfacetoremovevisibletissueresidueandfluid.
2. Dependingonthetypeofwhirlpooljetsthatareinyourtub,closealljetsbyperforming
oneofthefollowing:
•Turnthe centeroftheje tclockwisetoafullstop.
•Pushthecenterofthejetin.
3. Closethewhirlpool inletbygentlypullingthepl uginthecenteroftheinletcoveroutw arduntilitstops.
4. Openaeratorbyrotatingaeratorknobtwoturnscounter‐clockwise.
5. Open
disinfectantcabinet.
6. Ensurethatdisinfectantsiphontubeisplace dindisinfectantcontainer.
7. Iftubis equippedwithadisinfectantwand,holdthewandove rtheinteriorofthetub.
8. Adjustwatertemperatureto105°F(40°C).
9. TurndisinfectantOn/OffvalvetotheOnposition.
NOTE:Liquidwillbegi nflowingfr omthedisinfectantwandinto
thetub(ifsoequipped).
10. Turntheadjustmentknobontheflowmeteruntilthefloatingballrisestoalev elof35cc/min.
NOTE:At35cc/min.,disinfectantisbeingmixedwithwaterattheproperratio.
11. Continuetoholdthedisinfectantwandove rthe
interiorofthetub(ifsoequipped).
NOTE:
Whendisinfectanthastotallyfilledtheinteriorplumbing,
liquidwillbegintoflowfromtheburpfittinglocatedinsidethetub
bowlneartherimorfromthedisinfectantwand.
NOTE:Invacar erecommendsthatyouthoroughlyscruball
interiorsurfacesof thetub withdisinfectant.Theuseofalong‐
handled
brushwillmakethisoperationeasier.
12. Performoneofthefollowing:
•Allowsomeliquidtopoolinth ebottomofthe
tub.Scruballinteriorsurf acesofthetub,
includingthewhirlpooljets,overflowfitt ingand
whirlpoolinletfittingwithdis infectant .
•Ifthetubisequippedwithadisinfectantwand,
spraythe
interiorsurfac esofthetub,includingthe
whirlpooljet s,overflowfittingandwhirlpool
inletfittingwithdisinfectant.Scru ballin terior
surfaces.
13. TurnthedisinfectantvalvetotheOffposition.
14. Returndisinfectantwandtoitsholder(ifsoequipped).
15. Afterscrubbingtheinteriorsurf aces, leavethe
disinfectantintheloopan d onthe
tubsurfacesforten
minutes.
16. Rev erseSTEPS2and3toopenthewhirlpooljet sand
inlet.
17. Settheshower/massagewandto thepulsesettingand
directthe sprayintobothwhirlpooljetsto backflush
untilthewaterdi scharg ingfromthewhirlpoolinletis
clear.
18. Rinseallinteriortubsurfaces.
FIGURE 3.1 Disinfecting the Tub
Push In To
Close
Whirlpool Inlet
Plug
DETAIL “C” -
FLOWMETER DETAILS
Flowmeter
Floating
Ball
Knob
DETAIL “B” - DISINFECTING CABINET
Disinfectant
Valve
Flowmeter
Disinfectant
Siphon Tube
Turn Clockwise
to Close
Whirlpool Jet
DETAIL “A” - WHIRLPOOL JET AND INLET DETAILS
To Next Page
