SECTION 4—SAFETY INSPECTION/TROUBLESHOOTING
Side Entry Whirlpool Tub 32 Part No 1118387
11. Closealljetsbypushingthecenterofeachjetinorturningthecenterofthejet
clockwise.
12. Closethewhirlpoolinletbypullingtheinletplugout.
13. Turnthedisinfectantvalvetotheonposition.
NOTE:Liquidwillbeheardfillingtheinteriorplumbingofthetub.
14. Notethepositionofthefloatingballintheflowmeter.
15. Adjusttheinjectorbyperformingoneofthefollowing:
• BottomofFloatingBallReadsGreaterThan35‐Lessdisinfectantneedstobe
addedtothemixture.Loosenthescrewontheinjectortodrawlessdisinfectant
intothesolution.
• BottomofFloatingBallReadsLessThan35‐Moredisinfectantneedstobeadded
tothemixture.Tightenthescrewontheinjectortodrawmoredisinfectantintothe
solution.
16. Whenthebottomofthefloatingballisnear35,turntheblackadjustmentknobonthe
flowmeteruntilthebottomofthefloatingballisat35.
17. Placethebucket/pailundertheburpfittingtocollectthedisinfectant.Useafunnelif
necessary.
18. Notethenumberofouncesinthegraduatedplasticbottle.
19. Letthebucket/pailfilltoonegallon.
20. Turnthedisinfectantvalvetotheoffposition.
21. Removethedisinfectantdrawtubefromtheplasticbottle.
22. Examinetheamountofdisinfectantremainingintheplasticbottle.
23. SubtracttheamountofdisinfectantremainingfromtheamountnotedinSTEP18.
24. Performoneofthefollowing:
• Approximately½‐ounceofdisinfectanthasbeenused‐ProceedtoSTEP23.
•Muchmoreormuchlessthan½‐ounceofdisinfectanthas
beenused‐repeat
STEPS1‐18.
25. Positionthedisinfectantdrawtubeintothedisinfectantsolution.
26. Disinfectthetub.RefertoDisinfectingtheTubUsingtheClosedLoopSystemon
page 23.
