Invacare 6417 - Operating the Overbed Table; Adjusting Table Height; Adjusting Table Angle

Deluxe Overbed Table 2 Part No 1143201
FIGURE 1 Assembling/Disassembling
Operating the Overbed Table
NOTE:Forthisprocedure,refertoFIGURE 2onpage3.
Adjusting Table Height
 WARNING
ALWAYS check to ensure latching mechanism/height adjustment lever, located underneath the
table top, is properly engaged prior to use.
NOTE:Atransportscrewisusedtosecurethetabletoptothemastinthelowestpositionduringtransportation.Thetransportscrew
islocatedonthemastjustbelowthetabletop.
1. Removethetransportscrewandsaveforfutureuse.RefertoTransporting
onpage 3.
2. Squeezethelatchingmechanism/heightadjustmentleveruptowardthetabletop.
3. Adjustthetabletoptothedesiredheight.
NOTE:WhenperformingSTEP4,becarefulnottopresstoohardotherwisethetabletopwillrunthroughmultiplelatchingpointsbefore
lockinginplace.
4. Lightlypressdownonthe
tabletopuntiltabletopislockedinplace.An“audible”clickwillbeheardwhenlatching
mechanismsecurestabletopinplace.
Adjusting Table Angle
NOTE:AdjustingtableangleisavailableonModel6418only.
1. Squeezetheangleadjustmentleveruptowardthetabletop.
2. Tiltthetabletoptothedesiredangle.
3. Releaseangleadjustablelevertolockinplace.
Mounting
Screws
Bolts
Washers
Inserts
Casters
Casters
Table Top
Base
Tilt Table Top
Bolts
Washers
Inserts
Casters
Casters
Bolt
Washer
Nut
Supporting
Bracket
Mast
Base
Mast
Mounting
Holes
Model 6417
Model 6418
