Invacare 6417 - Transporting

Part No 1143201 3 Deluxe Overbed Table
FIGURE 2 Adjusting Table Height - Adjusting Table Angle
Transporting
CAUTION
Before taking the overbed table apart, adjust the table top to the lowest position and replace the
transport screw so the mast is locked in place before being packed and shipped otherwise dam-
age may result.
1. Adjusttabletolowestheightposition.RefertoAdjustingTableHeightonpage 2.
2. Installthetransportscrewtolockmastinplace(FIGURE 2).
3. Removethetabletopfromthemast.RefertoAssembling/Disassembling
onpage 1.
Transport
Screw
Latching Mechanism/
Height Adjustable
Lever
Angle Adjustment Lever
(Model 6418 only)
NOTE:OnlyModel6418isshown.
