Invacare®Action2NG
Adjustingtheheight
1.LoosenthescrewBwith5mmAllenkeyinthegroove
Cofthearmresttube.
2.Movethearmrestupwardsordownwardsuntilyou
reachthedesiredheight,whilekeepingscrewBin
place(atthetopedgeoftheholder).
3.TightenthescrewB(5–6Nm).
4.Performthesettingonbothsides.
3.8.2Armrest,foldableandremovable
Folding
1.Gripthearmrestbythearmpadorbythefrontcurve
andfolditback.
Frontremoving
1.PressandholdthearmrestreleasepushpinAatthe
front.
2.Removearmrestfromarmrestsocketbypullingstraight
upandfolditback.
Fronttting
1.Pushthearmrestdownanduntilthefrontrelease
buttonBsnapsintoitsarmrestsockethole.
2.Ensurebuttonprotrudesfullythroughsockethole.
Rearremoving
1.RemovearmrestfromarmrestbracketDbypulling
straightuponthearmrest.
Reartting
1.PositionarmrestsupportCoverreararmrestbracketD.
2.Pushthearmrestdownuntilaclear“click”isheard
whenit’slockedintothearmrestbracketD.
3.9Legrests
WARNING!
Riskofinjury
–Neverliftthewheelchairbythefootrest
supportsorlegrests.
CAUTION!
Riskofpinchingorcrushingngers
Thereareswingmechanismswhereyoucould
trapyourngers.
–Becarefulwhenusing,swinging,disassembling
oradjustingthesemechanisms.
IMPORTANT!
Riskofdamagetothelegrestmechanism
–Donotplaceanythingheavy,orletchildren
sitonthelegrest.
201608216-C
