Invacare®Action2NG
1.LoosenthescrewinthestopblockB.
2.LoosenthehandwheelA.
3.Adjusttheheadresttothedesiredposition.
4.Re-tightenthehandwheelAdowntothetopofthe
headrestattachment.
5.SlidethestopblockB.
6.Re-tightenthescrew.
Itisnowpossibletoremovetheheadrestand
reinsertitinthedesiredpositionwithoutfurther
adjustments.
Depth/angleadjustment
1.LoosenthehandleD.
2.LoosenthescrewsC.
3.Adjustthedepthandangleoftheheadrest.
4.Re-tightenthehandleandthescrews.
4.4Tipperaid
Withthetipperaid,anassistantcantipthewheelchair
moreeasily,inordertonavigatestepsforexample.
WARNING!
Riskofoverturning
–Ensurethatthetipperaiddoesnotproject
beyondtheexternaldiameteroftherear
wheel.
1.Holdthewheelchairbythepushhandles.
2.Pressthetipperaidwithyourfootandholdthe
wheelchairinthetippedpositionuntilyouhave
overcometheobstacle.
4.5Tabletray
WARNING!
Riskoftipping/injury
–Maxloadonthetable:8kg
281608216-C
