Invacare®Action2NG
11TechnicalData
11.1Dimensionsandweight
Alldimensionanweightspecicationsrefertoawiderange
ofthewheelchairinastandardconguration.Dimension
andweight(basedonISO7176–1/5/7)mayalteraccording
todifferentcongurations.Insomecongurations,the
wheelchairexceedtherecommendeddimensionsfora
wheelchair.
IMPORTANT!
–Insomecongurations,theoveralldimensions
ofthewheelchairwhenitisreadyforuse
exceedstheauthorisedlimitsandtheaccessto
emergencyescaperoutesisnotpossible.
–Insomecongurations,thewheelchairexceeds
thesizerecommendedfortravellingbytrain
intheEU.
Maximumuserweight125kg
A
Overalllengthwithleg
rests
870–1140mm
B
Overallwidth
540–710mm
Foldedlength
870–1140mm
Foldedwidth
255–355mm
Foldedheight
935mm
Totalmassfrom15–17kg
Massoftheheaviest
part
10–12kg
Staticstability
Downhill:0°–7°
Uphill:0°–15°
Sideways:0°–17°
Seatplaneangle
0°–8°
C
Effectiveseatdepth
435–460mm
D
Effectiveseatwidth
370–505mm,
inincrementsof25mm
E
Seatsurfaceheightat
frontedge
480mm,
inincrementsof25mm
F
Seatsurfaceheightat
rearedge
425mm,
inincrementsof25mm
G
Backrestangle
Range:0°/+30°
Fixed:7°–13°
Recliner:90°(0°/+30°),
inincrementsof10°
