Invacare®Action2NG
1.LooseningtheknobDandpullitupwithonehand
whilesupportingthelegrestwithyourotherhand.
2.Adjustintooneofninepresetpositions,downwards
theknobDintothedesiredpositionandrmlytighten
theknob.
Swingingcalfpadandadjustment
ThecalfpadEswingsawayduringtransfersandhasthree
depthadjustmentoptions.
1.AfterlooseningthexingscrewCadjusttothedesired
depthandrmlytightenthexingscrew.
Invacarerecommendsthatdepthadjustmentiscarriedout
byaqualiedtechnician.
Adjustingfootplate
Therearethreedifferentfootplatesavailable.
•Heightadjustablefootplates,version(1)
1.LooseningthexingboltBwith10mmspanner .
2.Adjustintooneoffourpresetpositionsandtighten
thexingbolt(5Nm)Bintothedesiredposition.
•Heightadjustablefootplates,version(2)
1.LooseningthexingscrewBwith5mmAllenkey.
2.Adjustintooneoffourpresetpositionsandtighten
thexingscrew(5Nm)Bintothedesiredposition.
•Height,depthandangleadjustablefootplates
1.LooseningthescrewFwith5mmAllenkey.
2.Adjustintothedepthandanglepositionsand
rmlytightenthescrew(12Nm)Fintothedesired
position.
Invacarerecommendsthatfootplateadjustmentiscarried
outbyaqualiedtechnician.
Toensureagoodpositionofthefeettheheelstrap
isattachedtothelegrestsupportandadjustableby
hookandloopfasteners.
3.10Anti-tipper
Ananti-tipperdevicepreventsthewheelchairfromtipping
backwards.
WARNING!
Riskofoverturning
Anti-tippersthatareincorrectlysetornolonger
workingcanleadtooverturning.
–Alwayscheckthattheanti-tipperisworking
beforeusingthewheelchairandhaveitset
orreadjustedbyaqualiedtechnicianwhen
required.
–Insomecongurations,thestaticstabilityof
thewheelchairmaybelowerthan10°;Invacare
stronglyrecommendstheuseofanti-tipper
(availableasanoption).
WARNING!
Riskofoverturning
Onunevenorsoftground,theanti-tippercansink
intopotholesordirectlyintotheground,thereby
curtailingoreliminatingitssafetyfunction.
–Onlyusetheanti-tipperwhentravellingon
evenandrmground.
22
1608216-C
