27
To adjust braking : turn the screw (C) counterclockwise to
increase braking force and turn clockwise to reduce it.
i The specic adjustments of hub brakes must always be
performed by your Dealer.
Always operate the two brakes simultaneously and do
not take slopes exceeding 5° to ensure perfect control of the
wheelchair steering !
2.6. Options
2.6.1 Seating options
- Back brace (photo 28) : it provides tension to the backrest
upholstery and provides the attendant better ergonomics
when pushing the wheelchair.
Note : it swings away to facilitate the wheelchair folding;
slightly loosen the button (A), pull up and swivel along the
backrest until it is in vertical position.
To reposition it, reverse the procedure and rmly tighten the
button (A) making sure that the button is properly tighten (B).
28
A
B
