3. Specications and tool
3.1. Standard wheelchair specications
Maximum user weight : 125 kg (150 kg)
Seat width : 38/40.5/43/45,5/48 cm
(50,5/55,5/60,5 cm)
Seat depth : 40/45 cm
Floor/seat height : 51/48.5/46/43.5/41/38,5 cm
Rear wheel : 24" (610 mm) pneumatic tyre
Castors : 8" (200 mm) solid tyre
Parking brake : Manual brake
with indexed brake shoe
Backrest : Fixed, folding and reclining
Armrests : Removable, removable and
swing-away
Footrest supports & Legrests : Removable and swing-away
Seat upholstery : Black nylon on reinforced
upholstery
Frame : Aluminium, epoxy coated
Wheelchair average weight : 15 kg
3.2. Tools for adjustments and regular maintenance
(not supplied)
Function Tool
Brake 5 mm Allen key
Footrest tube 5 mm Allen key
Footplate 5 mm Allen key
Adjustable armrests n°5 5 mm Allen key
Simple armrests n°1 4 mm Allen key
10 mm open-end wrench
Armpad T20 Torx key
Castor 13 mm open-end Wrench(X 2)
Quick-release axle 19/27 mm open-end wrench
11/19 mm open-end wrench
After sale and disposal recommendations
• It is compulsary to use original Invacare
®
spare parts which
you can buy through any Invacare
®
dealer.
• For repair, please contact your local Invacare
®
dealer.
• Disposal : the metal parts can be disposed of for scrap
metal through recycling. Plastic parts are disposed of as plastic
scrap.
Disposal must be carried out in accordance with the res-
pective national regulation. Please apply to your municipal
authorities/local government for details about local disposal
companies.
