Invacare Action 4 User Manual

2
3
A. GENERAL GUIDELINES
Page
1. Safety and operating limits
1.1 Reaching an object from the chair 3
1.2 Transferring to other seats 5
1.3 Tilting 6
1.4 Tilting, kerbs 6
1.5 Stairways 7
1.6 Slopes 7
2. Operating instructions
2.1 Folding and Unfolding the wheelchair 8
2.2 Wheelchair propulsion 9
2.3. Lifting the wheelchair 9
3. Safety inspection and maintenance
3.1 Performance control 10
3.2 General inspection
10
4. Transportation
4.1 Observations 12
4.2 Restraint systems 13
5. Summary of warranty terms
5.1 Standard terms 14
5.2 Limitation of liability 14
6. Summary of operating instructions 14
B. DESCRIPTION OF YOUR CHAIR
Page
1. Presentation
1.1 Introduction 15
1.2 General description 15
2. Adjustments
2.1 Seat 16
2.1.1 Seat upholstery 16
2.1.2 Type of Backrest 17
2.1.3 Backrest upholstery 18
2.1.4 Footrest supports 19
2.1.5 Armrests 20
2.1.6 Comfort version 21
2.2 Frame 23
2.2.1 Side frame 23
2.2.2 Double folding system 23
2.2.3 Steering tube 23
2.3 Rear wheel 24
2.3.1 24" & 22" wheels 24
2.3.2 Handrims 24
2.3.3 Axles 25
2.4 Castors 25
2.4.1 8", 6" & 5" wheels 25
2.4.2 Front fork 25
2.5 Brakes 26
2.5.1 Manual brakes 26
2.5.2 Hub brakes 27
2.6 Options & accessories 27
2.6.1 Seating options 27
2.6.2 Propulsion options 28
2.6.3 Safety equipment and options 30
2.6.4 Other options 31
3 Specication and tool
3.1 Standard wheelchair specifications 32
3.2 Tools for adjustments and regular maintenance (Not supplied) 32
3.3 Dimensions 33
TABLE OF CONTENTS

Invacare Action 4 Specifications

General

Foldable	Yes
Frame Material	Aluminum
Seat Depth	16 inches
Weight Capacity	135 kg
Total Width	Seat width + 19 cm (with 24'' wheels)
Maximum User Weight	135 kg
Overall Width	Seat width + 19 cm (with 24'' wheels)
Wheel Size	24 inches
Armrests	Optional
Footrests	Optional
