11 SETUP/MAINTENANCE
Invacare
3G Storm Series® 118 Part No 1143151
FIGURE15 Adjusting the Extended Active Anti-Tippers
DETAIL A DETAIL B
Standard Anti-
Tippers
Extended Active
Anti-Tippers
Extended Active
Anti-Tipper
Assembly
Install Dust Cover Here
Locknut C
Bearings
Locknut A
Locknut B
¼-Inch Block
Ground/Floor
Wheel
