Invacare Arrow - SPJ, MK6 i SPJ+ w;PSS and MK6 i SPJ+ w;ACC Joystick Switches and Indicators

8 WHEELCHAIR OPERATION
Part No 1143151
53 Invacare 3G Storm Series®
8.2 SPJ™+, MK6i™ SPJ+ w/PSS and MK6i SPJ+ w/ACC Joystick Switches and Indicators
FIGURE3 SPJ™+, MK6i™ SPJ+ w/PSS and MK6i SPJ+ w/ACC Joystick Switches and Indicators

For this procedure, refer to FIGURE3.
On/Off Button
Charger/
Programming
Input
Speedometer
Joystick
GREEN LED
Information
Gauge Display
Service Indicator
Decrease Speed Button
(Tortoise)
Increase Speed Button
(Hare)
Mode Button*
Additional Input for
Powered Seating
Switch
Active
(If Programed)

*The mode button is only present on SPJ+ w/ACC joystick.
